Yamaha Nmea 2000 Cable Simrad

I added a water pressure sensor 69j 8a4l0 15 00 from simyamaha to my engine and got water pressure.

Yamaha nmea 2000 cable simrad.

Installations with no command link connect using yamaha data connector connects un der engine cowling to standard nmea 2000 micro c adapter. Cabled sensor for yamaha outboard engine connects to nmea 2000 networks for engine data display. Yamaha to nmea 2000 gateway. To connect navico nmea 2000 devices to a yamaha command link system the yamaha engine gateway cable mar gtway ml 09 pictured above will be used to extend the backbone of the network by changing it from the yamaha connector system to the standard nmea 2000 connector system.

If you are connecting to an existing nmea2000 network don t forget you ll need another t connector for our adapter cable. I have oil pressure water temperature tachometer and voltmeter. I connected this to a yamaha f200xb outboard and a simrad go7 via a nmea 2000 network. 5 0 out of 5 stars 4.

Our adapter cable is also only 18 long so you may need a nmea2000 extension cable. If your yamaha is 2006 or newer with command link it is more than likely nmea 2000 capable. Yamaha nmea 2000 gateway device. I converted my yamaha f115lb to nmea 2000 displays on my simrad nss 7 evo 2 chartplotter from factory round 6y8 commandlink gauges without a 6yc unit which was priced at 1600 for only 100.

1 ft or longer pigtail buss wire is required to connect the gateway to 3 port command link hub. The interface cable comes with a nmea 2000 network t connector. Includes interface sensor 15 cable and network bus t connector. Garmin t connector garmin nmea2000 cable simrad lowrance t connector simrad lowrance extension cable.

Ease of installation. I connected two pink wires together to get the trim tilt indicator to work. Lowrance low 000 0120 37 nmea 2000 yamaha engine interface mfg 000 0120 37 between a yamaha engine and nmea 2000 network to display engine data. Simrad yamaha engine interface cable 17 4 5 stars 17 reviews skips to reviews.

Installations with command link connect using yamaha command link gateway. Works with both the command link plus color display and command link square or round gauge systems. This part is for the gateway only and does not come with the pigtail buss wire that is needed. To display engine instruments on your simrad you ll need a simple lowrance yamaha engine interface cable connected to your nmea 2000 backbone.
